9. Assemble and Install the Pedals
Step 9B:
The pedals are stamped on the threaded end of the
axle with the letter “R” and “L” for Right and Left
respectively. Right and Left sides are determined as
you would use the recumbent bike. Install the Right
pedal on the Right crank arm using the included
wrench (117) or a 15 mm wrench. Install the Left
pedal on the Left crank arm using the included wrench
(117) or a 15 mm wrench. NOTE: The Left pedal
is reverse thread (you must turn it
counter-clockwise to tighten it).
Step 9A:
Install the toe straps on the pedals as shown in Fig A to
the right.
B
A
17
