2. To assemble the Rear Stabilizer
STEP 2A: As shown to the Right,
attach the Rear Stabilizer (74) to the
Frame (1) with Bolts (109), Washers
(113) (112) and Acorn Nuts (110), then
tighten with the included wrench (117)
or a 13mm wrench or socket.
Spring washer M8х2.0t—2PCS(112)
Washer 20х9х2.0t—2PCS(113)
M8 Acorn Nut—2PCS (110)
Bolt M8х56—2PCS
109
9
