Pacific energy SUMMIT - Dimensions; Mantel Clearances

6 SINC 050515-24
©PACIFIC ENERGY FIREPLACE
PRODUCTS LTD.
Dimensions
40 7/8”
23 5/16”
25 3/8”
27 9/16”
B
A
28 7/8”
18”
10 7/8”
22 1/4”
6 5/8”
12 1/4”
22 15/16”
9 1/8”
Mantel Clearances
A 15”
MANTEL CLEARANCE
CHART
A
12"
A 50 3/8” 54 3/8"
B 32 3/16” 34 3/16"
SURROUND
DIMENSIONS
REGULAR
SURROUND
OVERSIZED
SURROUND
