Pacific energy Super Insert DESIGN-D - Page 4

4
SPND.BODYA 300309-24
16”
Non-combustible replace
hearth
24”
21”
18”
8”8”
Fireplace hearth requirements:(Measured without the insert)
The non- combustible replace hearth must be raised 2” above an adjacent combustible oor and extend 16” in front and
8” beyond each side of the existing replace opening. A non-combustible hearth that extends a minimum 23 1/2” in front
of the replace opening may be ush to an adjacent combustible oor.
Ember protection:
Combustible oor in front of the replace insert must be protected from hot embers by non-combustible material extending
16” to the ring side and 8” to other sides of the unit.
Consult CAN/CSA-B365 Installation Code for Solid-Fuel-Burning appliances and equipment in Canada, and N.F.P.A. 211
Standard for chimneys, replaces, vents and Solid-Fuel-Burning appliances in USA.
16”
Non-combustible replace
hearth
Non-combustible oor
covering
2”
2”
2”
21 3/4”
18”
*
*
**
**
MINIMUM EMBER
PROTECTION
DIMENSIONS
MINIMUM FIREPLACE
OPENING AND HEARTH
DIMENSIONS
22 1/2”
