OPTIONAL ONBOARD CHARGER
ITEM QTY PART NUMBER DESCRIPTION
1 1 850804 BRACKET, MTG, CHARGER
2 2 W189D SCREW, HEX, 1/4-20 X .75, SS, PATCH
3 2 980002 WASHER, LOCK, SPLIT, .25
4 2 W104D WASHER, FLAT, .25
5 1 852407 CHARGER, 24V, ONBRD, CULUS
6 4 962186 SCREW, PAN, #10-32 X 1.0, SS
7 4 W401D WASHER, FLAT, #10
8 4 920666 NUT, NYLOCK, #10-32, SS
9 1 920034 NUT, NYLOCK, #6-32, SS
10 1 W132D SCREW, PAN, #6-32 X 1.0, ZINC
11 1 850805 BRACKET, MTG, CORD
12 2 962263 SCREW, BUTT, SOCK, .25-20X.62, SS BO
13 1 911645 HARNESS, CHARGER, POST
14 2 852101 CLAMP, WIRE, P-SHAPED
15 2 501210 BUMPER
