SQUEEGEE ASSEMBLY
ITEM QTY PART NUMBER DESCRIPTION
1 1 853203 FRAME SQUEEGEE 30 INCH
2 1 850702 BLADE REAR 30 INCH LINATEX
3 1 857201 RETAINER REAR 30 INCH
4 1 850701 BLADE FRONT 30 INCH LINARD
5 1 857202 RETAINER FRONT 30 INCH
6 2 852002 CLAMP, OVER-CENTER, BAND
7 4 920034 NUT, NYLOCK, #6-32, SS
8 2 962465 SCREW, SHOULDER, .50 X .50
9 2 859703 WHEEL, GUIDE
10 2 920035 NUT, NYLOCK, .38-16, SS
11 1 850704 BLADE, REAR, 30 IN, URETH (OPTIONAL)
12 1 850703 BLADE, FRONT, 30 INCH, URETH (OPTL)
13 2 980093 WASHER, WAVE, .50INCH
