SPECIFICATION & TECHNICAL DATA
Model P-80
Inlet and Outlet Diameter 3.0"
Flow Capacity(L/Min) 1
000
Suction Head(Meter) 7
Delivery(Meter) 28
Pump Set Package Dimension(mm) 530X390X465
Gross Weight of Pump Set(KG) 27.5
Engine(HP) 5.5
P
UMP CURVE
3' water pump
0
5
10
15
20
25
30
0 200 400 600 800 1000 1200
Flow (L/min)
Total Head(m)
O
PERATION
PUMP PLACEMENT
For best pump performance, place
the pump close the water level
\and use hoses that no longer
than necessary. That will enable
the pump to produce the greatest
output with the least self-priming time.
As head (pumping height) increases,
output decreases. The length, type,
and size of the suction and discharge
hoses can also significantly affect pump
output.
Discharge head capability is always greater than suction head capability, so it
is important for suction head to be the shorter part of total head. Minimizing
suction head is also very important for reducing self-priming time.
