RX3i Redundancy Memory Xchange Module 5
GFK-2511H
Functional Compatibility
The RMX requires the following versions for configuration and operation.
Programmer Version Requirements
PME version 5.90 SIM1 or later must be used for compatibility with the
RMX128 module.
RX3i CPU firmware 7.75 (or later) is required to be used with RMX128
hardware version –Cx and firmware version 2.00.
PACSystems RX3i CRU320 is required for use in a redundancy system.
Firmware version 2.00 is not compatible with earlier hardware versions.
Firmware versions earlier than 2.00 are not compatible with 2.00 and later
(-Cx and later) hardware versions.
The RMX128 must be located in the main RX3i rack. IC695RMX128
modules require a PCI backplane, which is not available on
IC694CHSxxx expansion bases.
Problems Resolved by Release 2.00
Memory Read Data Corruption
Revision -CG prevents the rare condition of corruption during a
memory read from occurring. This condition was seen by users as
a broken redundant link on an RMX128.
Restrictions and Open Issues in this Release
RX3i RMX/CMX modules require
grounded ESD strap for EMC Installation
When installing, operating, or maintaining the IC695RMX128,
personnel must insure any electrostatic charge is discharged
through the use of a grounded ESD strap or other means to meet
IEC-61000-4-2 (ESD) requirements. A direct electrostatic discharge
event of 4kV or higher applied to the metal optical transceiver
housing may result in a lights out module requiring a power cycle to
recover.
RX3i RMX and CMX modules require a
metal enclosure to meet radiated
emissions requirements.
For installation requirements, see “Government Regulations” on
page 3.
