paladin JRB SMART-LOC

Questions and Answers

B
brobertsAug 15, 2025
Why paladin Construction Equipment coupler cylinder does not extend?
- J
  Jason GriffithAug 15, 2025
  If the coupler cylinder on your paladin Construction Equipment isn't extending, it could be due to several reasons. The hoses or valve might be blocked by dirt, in which case you should remove and clean them, then blow air through the valve to check its operation. Another possibility is incorrect pressure; check the pressure in the coupler cylinder extend “EXT” line (High Pressure System - full system pressure, Low Pressure System - 3250 PSI), inspect the coupler cylinder check valve o-rings for damage, and ensure the hoses aren't pinched or the fittings/coupler cylinder tubes are not damaged. Lastly, the locking mechanism may be binding; remove any debris from the coupler and lubricate the coupler grease points.
H
huntjoyAug 26, 2025
What to do if the secondary lock arm on my paladin Construction Equipment does not disengage at full curl?
- R
  rklineAug 26, 2025
  If the secondary lock arm on your paladin Construction Equipment fails to disengage at full curl, it may be due to excessive wear on the lock arm. Replace the lock arm to resolve this issue.
S
Sarah EdwardsNov 5, 2025
What to do if the paladin Construction Equipment coupler cylinder does not retract?
- O
  owhiteNov 5, 2025
  If the coupler cylinder on your paladin Construction Equipment doesn't retract, several factors could be at play. First, the bucket cylinder might not be relieving pressure. Second, dirt may be plugging the hoses or valve; in this case, remove and clean the hoses and valve, then blow air through the valve to verify its operation. Third, there may be incorrect pressure; check the pressure in the coupler cylinder retract “RET” line (High Pressure System - full system pressure, Low Pressure System - 3250 PSI). Finally, check electrical connections and primary ground, and ensure the correct voltage is supplied to the coils (12 volts to 12-volt coils and 24 volts to 24-volt coils). Also, remove debris from the coupler and lubricate the grease points. Ensure the coupler is rotated to the full cu...

Summary

Preface and General Information

General Comments

General remarks and product introduction for the JRB Smart-Loc Coupler.

Before Operation Guidelines

Operator responsibilities and emphasis on reading the manual before use.

Safety Alert Symbol Explanation

Explanation of the industry-standard safety alert symbol for warnings.

Service and Unit Information

Guidance on using replacement parts and recording unit serial numbers.

Sound and Vibration Factors

Factors influencing sound pressure and vibration levels for the attachment.

Safety Statements and Precautions

Hazard Signal Word Definitions

Definitions of DANGER, WARNING, CAUTION, and NOTICE signal words.

General Safety Precautions

Fundamental safety rules for installation, operation, and maintenance.

General Safety Precautions Continued

Protect Against Flying Debris

Safety measures for operations involving potential flying debris.

Lower or Support Raised Equipment

Procedures for safely lowering or supporting raised equipment.

Hydraulic Fluid Pressure Safety

Precautions and warnings regarding high-pressure hydraulic fluid hazards.

More General Safety Precautions

Equipment Modification Warning

Warning against unauthorized modifications compromising safety and integrity.

Safe Maintenance and Repair Practices

Guidelines for performing maintenance and repairs safely.

Safe Equipment Operation Rules

Essential rules for operating the equipment responsibly and safely.

California Proposition 65 Notice

Notice regarding chemicals known to cause cancer or reproductive harm.

Equipment Specific Safety Precautions

Utility Line Awareness

Reminder to identify and avoid underground utilities before digging.

Silica Dust and Hazardous Dust Exposure

Health warning about dust exposure and recommended protective measures.

Paint Removal for Heating Processes

Safety procedures for removing paint before welding or heating.

End of Life Disposal Procedures

Guidelines for environmentally responsible disposal of the unit.

Attachment Operating Safety Rules

Essential safety rules for operating the attachment correctly.

Ground Clearance for Lock;Unlock Operations

Safety instruction for attachment lock/unlock operations.

Further Equipment Safety

Coupler Debris Clearing

Importance of keeping the coupler clear of debris for proper function.

Attachment Reach and Interference Awareness

Understanding how coupler affects reach and potential interference.

Bucket Orientation Warning

Warning against reverse bucket orientation due to safety and function.

Machine Stick Modification Impact

Caution about machine stick modifications affecting coupler operation.

Operational Safety Details

Lift Eye Usage Guidelines

Correct and safe usage of the coupler's integrated lift eye.

JRB Hydraulic Kit Requirement

Warning against using non-JRB hydraulic systems for coupler operation.

Attachment Transport Safety

Safety guidelines for transporting the coupler and its attached implements.

Measuring Travel Dimensions

Advice on measuring overall dimensions with coupler and attachment installed.

Maintenance and Attachment Safety

Pre-Maintenance Safety Checks

Safety procedures to follow before performing any maintenance tasks.

Detach Attachment After Use

Importance of detaching the attachment from the coupler at the end of each shift.

Decals and Labeling

Decal Placement and Information

Overview of decal locations and their importance for safety and longevity.

Installation Guide

Component Nomenclature

Identification and labeling of key components within the coupler system.

Installation Procedure Steps

Step-by-step guide for securely attaching the coupler to the machine.

Operation Procedures

Intended Use and Misuse Examples

Defines proper applications and illustrates prohibited uses of the coupler.

Locking Mechanism Details

Explanation of the coupler's primary and secondary locking systems.

Coupler Control Box Operation

Using the control box for locking, unlocking, and troubleshooting.

High Pressure Hydraulic Schematic

Diagram of the high-pressure hydraulic system for the coupler.

Low Pressure Hydraulic Schematic

Diagram of the low-pressure hydraulic system for the coupler.

Locking Attachment Procedure

Step-by-step guide for securely attaching an implement.

Unlocking Attachment Procedure

Step-by-step guide for safely detaching an implement.

Storage Guidelines

Guidelines for proper storage of the coupler.

Lift Point Identification

Identification and safe usage of designated lifting points.

Tie Down Point Identification

Identification and safe usage of designated tie-down points for transport.

Transporting the Attachment

Safety regulations and recommended practices for transporting the attachment.

Maintenance and Service

General Maintenance Information

Importance of maintenance for equipment longevity and safe operation.

Maintenance Schedule Overview

Table outlining daily, weekly, and per-interchange maintenance tasks.

Coupler Greasing Instructions

Daily lubrication requirements for coupler components to maintain working condition.

Hydraulic Cylinder Service

Procedures for pre-removal, removal, and replacement of the hydraulic cylinder.

Troubleshooting and Specifications

Common Problem Resolution Guide

Table of common coupler issues, their causes, and suggested solutions.

SAE Torque Values

Torque values for SAE grade bolts used in applications.

Metric Torque Values

Torque values for metric grade bolts used in applications.

Parts and Warranty Information

Parts Ordering and Service Contact

Information for ordering replacement parts and contacting the service department.

Warranty Policy Information

Details on warranty statements, procedures, and claim forms.
