Palazzani
Palazzani Industrie spa
OM 386 pag 12 Cap 3
Stop the platform before inverting the drive sense
against overturging risks, it is recommended to drive with the stabilizing legs
enlarged and lowered near the ground
WARNING
Platform is not admitted to road circulation and, therefore, driving on an area
opened to the traffic needs necessary protections and signals.
Many times an authority authorisation for the manufacturing site is necessary.
If not possible, follow the machine by the truck or by another vehicle with
emergency lights on.
The operator must drive the machine on the sidewalk by paying attention to
eventual obstacles or people present on the way.
The transfer on a public area must be short, made in favourable hours, and if
necessary with the police approval.
3.9 SPECIAL BOOM ACTIVATION
In case of a strong slope or loading ramps, the boom can be lifted at the necessary
angle to avoid that the cage touches the ground without put stabilizers on the
ground.
Act as following:
• the boom must be with extension completely retracted
• with the engine on, push the button part. 2 in fig. 3.2 and contemporarily,
from the ground controls panel, lift the boom up (part.6 Fig. 3.6).
• when the operation is finished, repeat the operation on reverse to bring the
boom back to horizontal position
Do not lift the cage floor more than 80 cm from the ground.
3.10 STEERING
It is controlled varying the speed of the tracks, by means of the corresponding
control lever.
Platform can be also be rotated, acting on the two levers 1 and 5 of Fig. 3.6 at the
