Palazzani
Palazzani Industrie spa
OM 386 pag 13 Cap 3
same time and in contrary sense. It is advised to make this manoeuvre at a low
speed and on flat and regular ground, only
3.11 AUTOMATIC BRAKE
No braking control is necessary, as the platform is provided with an automatic
system consisting of mechanic negative brakes, with hydraulic release and
overcentre valves, mounted on transmission hydraulic motors
Slow speed pre-selection 10 of Fig. 3.6 increases braking action and, therefore, it is
recommended for driving and parking on a slope
3.12 LEVELLING THE MACHINE
Stabilizing legs can be individually rotated and articulated, according the owner
needs.
Once detect the desire position it’s indispensable to insert the pins in the
appropriate holes (fig. 3.12).
Fig. 3.12
always verify that the floor capacity is adequate to the pressure of each
outrigger (this value is signalled by a special label).
