OM 386 pag 17 Cap 3
NO
Fig. 3.18
The max slope between the two stabilisers plates laying floors
indipendently from the scarp must not excede 5° to avoid chariot sliding due to the
limited attrition resistance (Fig. 3.18).
3.13 AERIAL WORK
Access to the platform
Access to the platform with retracted boom and cage near the ground. Materials
also must be loaded this way.
Operators must not exit and access from the cage from high position.
Stay on the cage only for lifting and working in high position. During the transfer,
operators must not stay on board.
It is possible but it is very dangerous
to load material when the machine is
placed and extended. Protections don’t grant all risks from a possible overturn.
If the light and the overloading acoustic alarm activates, quickly download the
exceeding load.
If the cage has to lift beyond an obstacle (river, difficult ground..) it is advisable
to try before with a similar weight (i.e. 2 persons) and check if the boom reaches
the wished position without stopping.
In this case it is always possible to safety lower the cage to the ground and lift
again.
After positioning the stabilisers on the ground and leveling the chariot, the machine
is ready for aerial work. Do the following: take the safety socket off (fig 3.19) used
for transport and use the control panel in the cage.
From this position it is possible now to operatively move the boom. In fig. 3.7 all
joystick manoeuvres are indicated.
It is possible to enable the aerial movement controls with the key also from a
different position from the usual one (for maintenance, regulations, rentals with
