23
PTV Primary Pump Valve Block Setup
Circuit board cover
S2 Valve-Lower
S1 Valve-Lift
S4 Valve-Open
S3 Valve-Close
S5 Valve-Lower
Return Fluid
Pilot Operated Check Valve
High Pressure control valve
Low Pressure control valve
