16
EN
USER MANUAL
Product number PILM
Product type Speaker simulation DI box
No. of channels 1
Type passive
Transformer isolated Yes
No. of inputs 1
Input type unbalanced
Input connections 6.3 mm jack
No. of outputs 1
Output type balanced
Output connections XLR
THRU outputs per channel 1
Input attenuation (pad) 0 dB / 15 dB / 30 dB
Ground/lift switch Yes
Additional functions Tone: Bypass, Normal, Bright, Mellow
Housing Aluminium continuous casting
Dimensions (H/W/D) 140 x 50 x 68 mm
Weight 0.445 kg
Ambient temperature for operation -20°C…70°C
Relative air humidity <80%, non-condensing
Included accessories Rubber feet, label (tour label)
AUDIO
Max. input level (<1% THD, 20 Hz) +12 dBu
Max. input level (< 1% THD, 1 kHz) +32 dBu
Frequency response (±1 dB, relative 1 kHz) 10 Hz–60 kHz
Input impedance (1 kHz, setting: bypass, 0 dB PAD) 8.8 kΩ
Output impedance (1 kHz, setting: bypass, 0 dB PAD) 125 Ω
THD (30 Hz, +4 dBu, unity, unweighted) < 0.25%
THD (1 kHz, +4 dBu, unity, unweighted) < 0.009%
IMD (SMPTE) (60 Hz/7 kHz, 4:1, +4 dBu) < 0.005%
Transformer ratio 1:5
All measurements were performed with a generator with 600 Ω output impedance and 1 kΩ balanced load.
TECHNICAL DATA
GENERAL
