Palsonic TFTV4932LED - Names of each Part (Back View)

4
7
Power Connecting
1. Connect the small round plug on the power adaptor cable to the power
input socket at the rear of the set.
2. Connect the mains cable between the power adaptor and the mains supply.
Power adaptor
Mains cable
Names of each part
User Guidance Information
DC POWER IN(DC 12V 5A)
1 5
HEADPHONE OUT
9
HDMI
USB
2 6
RF
10
VGA(D-Sub 15PIN)
3
AV1
7
COAX OUT
11
PCAUDIOIN
8
YPbPr
4
L-in
AV 2
R-in
L-in
AV 2
R-in
1 2 3 4 5 6 7
9
10
11
8
USB
