Panamax M5500 - Table of Contents; Before You Begin

1
Before You Begin.........................................................1
I n t r o d u c t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connection Diagram....................................................3
Feature Overview.........................................................4
Feature Details
Analog Voltmeter & Ammeter.................................5
Convenience Lamp................................................5
Convenience Outlet................................................5
Diagnostic Lights...................................................6
Sequential Startup/Shutdown................................6
Filtered Outlet Banks 1 & 2.....................................7
Isolation Transformer Outlets.................................7
High-Current Outlet Bank.......................................8
Voltage Sense Trigger............................................8
Circuit Breakers.....................................................8
Coaxial Line Protection..........................................9
Telephone Line Protection......................................9
AC Power Cord......................................................9
AC Surge Protection............................................10
SurgeGate Plus™ Protection................................10
Technical Specifications.............................................11
Contacting Panamax..................................................11
Frequently Asked Questions.......................................12
TABLE OF CONTENTS
1 - MAX®5500 ACRegenerator
™
1 - RJ-11 Telephone Cable
4 - Coax Cables for
Satellite TV, Cable TV
and/or Antennas
4 - Rack ears w/ screws for
rack mounting option
1 - Convenience Lamp with 5W
halogen bulb
1 - IEC 320, 120V/15A,
10 ft. power cord
BEFORE YOU BEGIN
Items included with the MAX® 5500 ACRegenerator
™
:
Please verify that you have received all these items. If not, contact Panamax.
USA & Canada (800) 472-5555 • (707) 283-5900 • www.panamax.com
