Congratulations on your selection of
the MAX
® 5100 as the AC power
source for your audio/video system!
Over 25 years of power protection
experience and more than 10 years of
Audio/Video noise filtration engineer-
ing experience were utilized in the
development of this model. The MAX
®
5100 has been specifically engineered
to enhance the performance and life
expectancy of Audio/Video entertain-
ment gear. The combination of
sophisticated noise filtration circuitry
and the world’s finest surge protection
has resulted in an Audio/Video power
center that meets the power quality
needs for each piece of equipment in
your entertainment system.
© 2001 PANAMAX CORP. All Rights Reserved.
MAX® 5100 Owner’s Manual
MODEL # M5100
PANAMAX, the Panamax logo and MAX are registered US trademarks of Panamax.
Protect or Disconnect, SurgeGate Plus and SignalPerfect are trademarks of PANAMAX.
SIDACtor is a registered US trademark of Teccor Electronics, Inc. TiVo is a trademark of TiVo, Inc.
Before You Begin.........................................................1
I n t r o d u c t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Connection Diagram....................................................2
Feature Overview.........................................................3
Feature Details
Diagnostic Lights...................................................4
Sequential Startup/Shutdown................................4
Filtered Outlet Banks 1 & 2.....................................4
High-Current Outlet Bank.......................................5
Voltage Sense Trigger............................................5
Circuit Breaker.......................................................6
Coaxial Line Protection..........................................6
Telephone Line Protection.....................................6
AC Surge Protection.............................................7
SurgeGate Plus™ Protection.................................7
Technical Specifications.............................................8
Contacting Panamax...................................................8
Frequently Asked Questions.........................................9
TABLE OF CONTENTS
