DIGITAL PROGRAMMER CIRCUIT
PARTS LIST
(NN-S560BFAPH/CPH,S560WFAPH/CPH)
Ref.No. RemarksPart No.
Pcs/
Set
-31 -
Part name & Description
BZ310 AEFB22EP20TL BUZZER 1 2.0KHz
C12,C290,C291,C300,C301 AECUB2F104ZK CAPACITOR 5 0.1µF/25V
C330 AECUB5C102KK CAPACITOR 1 0.1µF/50V
C340 AECUB5F103ZK CAPACITOR 1 0.01µF/50V
C10 ECEA1VM471B ELECTROLYTIC CAPACITOR A 1 470µF/35V
C11 ECEA1CKA100B ELECTROLYTIC CAPACITOR A 1 10µF/16V
CN1 AEEMXF01505W CONNECTOR 1
CN2 AEEMMF00703W CONNECTOR 1
CN3 AEEMXF00703B CONNECTOR 1
CN4 AEEMXF00F04W CONNECTOR 1
CX320 AEFOS800MG06 CERAMIC RESONATOR 1 6.8MHz
D180,D181,D182,D183 AESQSML210MT LED 4
D10 AESSIN4003E DIODE,SI 1
D40,D41,D220,D221 MA196-(TA5) DIODE,SI 4
D25 AERZ271NS10D VARISTOR 1
D26,27 AERZB00NS10D VARISTOR 2
IC1 MN101C487DB1 L.S.I 1
IC220 AN6747B IC 1
Q181,Q40,Q220 2SC2412KT146 TRANSISTOR 3
Q10,Q180 2SD1859TV2Q TRANSISTOR 2
R100,R101,R102,R221 AERJ3GSYJ103 RESISTOR 4 10K,1/16W,50%
R40,R41,R42,R43,44,R45,
AERJ3GSYJ104 RESISTOR
9
100K,1/16W,50%
R46,R47,R48
R49 AERJ3GSYJ154 RESISTOR 1 150K,1/16W,5%
R220 AERJ3GSYJ222 RESISTOR 1 2.2K,1/16W,5%
R310 AERJ3GSYJ332 RESISTOR 1 3.3K,1/16W,5%
R330 AERJ3GSYJ333 RESISTOR 1 3.3K,1/16W,5%
R181 AERJ3GSYJ360 RESISTOR 1 36Ω,1/4W,5%
R480,R481 AERJ3GSYJ472 RESISTOR 2 4.7K,1/4W,5%
R311 RD16ST102J RESISTOR 1 1K,1/4W,5%
R180,R290 RD16ST103J RESISTOR 2 10K,1/4W,5%
R340 RD16ST104J RESISTOR 1 100K,1/4W,5%
R10,R11 RD16ST751J RESISTOR 2 750Ω,1/4W,5%
RY1 AEGG5G1A12 POWER RELAY 1
IC480 AEHMH705S SENSOR IC 1
T10 AETP284T0AP LOW VOLTAGE TRANSFORMER 1
ZD10 AESZMTAJ5R6B ZENER DIODE 1
