Panasonic Aquarea WH-ADC0309J3E5C - Buffer tank connection; Base pan heater; Bivalent connection

208 Aquarea air-to-water heat pumps - Planning and installation manual - 02/2022
Appendix
8
25
EN
Menus
Menu Default Setting Setting Options / Display
5.6
Buffer tank connection
To connect tank to the system
and if selected YES, to set
T temperature�
•The optional PCB connectivity
must be selected YES to
enable the function�
•If the optional PCB
connectivity is not selected,
the function will not appear on
the display�
No
Yes
5 °C
Set
T for Buffer
Tank
5.7
Base pan heater
To select whether or not
optional base pan heater is
connected�
* Type A - The base pan heater
activates only during
deice operation�
*Type B -The base pan heater
activates when outdoor
ambient temperature is
5 °C or lower�
No
Yes
A
Set base pan heater
type*�
5.8
Alternative outdoor sensor
To select an alternative outdoor
sensor�
No
5.9
Bivalent connection
To select to enable or disable
bivalent connection�
No
Yes
To select either auto control
pattern or SG ready input
control pattern�
* This selection only display
to select when optional pcb
connection set to Yes�
Auto
