Shutter Speed
OFF
1/100
1/250
1/500
1/1 000
1/2 000
1/4 000
1/10 000
-36-
@2 Electronic Shutter Setting [Shutter Speed: OFF/
1/100 to 1/10 000 / S/Scan / Auto ND]
OFF: Electronic shutter is turned off.
1/100, 1/250, 1/500, 1/1 000, 1/2 000, 1/4 000, 1/10 000:
Electronic shutter operates at one of these
speeds as selected.
S/Scan (Synchro Scan): Electronic shutter oper-
ates at the speed set with the electronic shutter
synchro-scan setting @3.
Auto ND: Electronic shutter is controlled to auto-
matically adjust the luminance. (ELC)
@3 Electronic Shutter Synchro-Scan Setting
[Synchro Scan: 60.34 Hz - 15.75 kHz]
This setting is possible only when Electronic Shutter
setting @2 is at S/Scan.
Horizontal bar noise can be reduced by synchro-
scan adjustment in shooting workstation scenes, for
example.
*
For luminance settings at each shutter speed and
synchro-scan shutter speed, refer to the table
below.
Required luminance ratio
1
2
4
8
16
32
64
160
Synchro-scan
-
99.68 Hz
250.0 Hz
492.2 Hz
984.4 Hz
1.969 kHz
3.938 kHz
7.875 kHz
@4 CCD Read Out Mode Setting [V Resolution:
Normal/Fine]
Normal: Normal image. (CCD storage will be by
field storage.)
Fine: Vertical resolution increases. (Vertical resolu-
tion is raised without increasing residual images
by frame storage and electronic shutter.
Normal is recommended for general use be-
cause sensitivity will decrease at the Fine set-
ting.
• In case of using the RCU (RCB), none of the shut-
ter speeds-1/250, 1/2 000, 1/4 000, and 1/10 000
can be selected.
• In case of using the hybrid control panel, only
OFF, 1/100, or Auto ND (ELC) can be selected.
• If the lens iris switch is at M (Manual) when oper-
ating the camera alone or when the iris switch on
the RCU (RCB) is at AUTO, Auto ND may not
function. Set the lens iris switch to A (Auto).
• Flickering may increase at Auto ND under fluores-
cent lights.
• Auto ND is automatically selected if Auto ND
(ELC) setting r is set to ON.
Notes
