GPI
The “GPI CONTROL” item is used to set enable/disable of all GPI functions, and assigns functions to each of the
GPI terminal pins (→ page 31).
The underlined values are factory preset setting values.
Sub menu Settings Explanation
GPI CONTROL DISABLE
ENABLE
GPI functions enable/disable settings
<DISABLE> Deactivate
<ENABLE> Activate
GPI1 - GPI8 UNDEF
MARKER1 ON/OFF
MARKER2 ON/OFF
MARKER BACK HALF
MARKER BACK BLACK
CENTER MARKER
INPUT SEL. YPBPR
INPUT SEL. VF
INPUT SEL. VIDEO
INPUT SEL. SDI
SD ASPECT
RED TALLY
GREEN TALLY
MONO
PIXEL TO PIXEL
FOCUS IN RED
Used to set the GPI control terminal pin assign.
You can set the same items for each terminal
(→ page 31).
Main Menu (continued)
