Audio Setting
Adjustment to each speaker and an optional subwoofer
CQ-C7305N
VOLUME
Main volume adjustment
(Setting range: 0 to 40, Default: 18)
q : Up
w : Down
BASS/TREBLE
Bass adjustment
(Setting range:
- 12 dB to +12 dB, 2 dB Step, Default:
Bass 0 dB)
q : Up
w : Down
BASS/TREBLE
Treble adjustment
(Setting range:
- 12 dB to +12 dB, 2 dB Step, Default:
Treble 0 dB)
q : Up
w : Down
Note: Do not activate SQ and Bass/Treble at same time
to avoid causing sound distortion.
BALANCE/FADER
Balance adjustment
(Setting range: L (left) 15 to R (right) 15 and Centre,
Default: Centre)
q : Right enhanced
w : Left enhanced
BALANCE/FADER
Fader adjustment
(Setting range: R (rear) 15 to F (front) 15 and Centre,
Default: Centre)
q : Front enhanced
w : Rear enhanced
SUB WOOFER
Subwoofer level adjustment
(Setting range : mute ( - ∞), - 6 dB to +6 dB, 2 dB Step,
Default: 0
dB )
q : Up
w : Down
LPF
Subwoofer Low Pass Filter
(Setting range: 80 Hz, 120 Hz, 160 Hz, Default: 80 Hz)
q : Up
w : Down
HPF
High Pass Filter
(Setting range: Filter OFF, 90 Hz, 135 Hz, 180 Hz, 225 Hz,
Default: Filter OFF)
q : Up
w : Down
REAR (SRS WOW)
Rear Level Adjustment
(Setting range: 0 to –15, Default: –10)
q : Up
w : Down
Note: The rear level is adjustable only when SRS WOW
is enabled. (a page 16)
Subwoofer output range
Other speakers output ranges
AUDIO Menu Display
1
Press [ PUSH SEL :
SELECT] to display
the AUDIO menu
display.
For using the remote
control, use [SEL] (MENU).
2
Press [ PUSH SEL : SELECT] to select a
mode to be adjusted.
For using the remote control, use [SEL] (MENU).
3
Turn [VOL] clockwise
or counterclockwise
to adjust.
For using the remote
control, use [VOL }] or
[VOL {].
Note: Only the VOLUME, SUB.W, LPF, and REAR are
adjustable when SRS WOW is enabled. (a page 16)
