Panasonic CQ-DP383U

Ref.
No.
Part No. Part Name & Description Remarks
[3032-14-02] CD Servo Block
IC’s and TRANSISTORs
IC201 MN6627482WB IC
IC202 YESAM163 IC
IC203 YESAM166 IC
IC204 C0ABBB000073 IC
IC401 YESAM176 IC
IC402 YESAM172 IC
IC406 YESAM171 IC
IC409 YESAM167 IC
IC411 YESAM178 IC
Q101 B1BDBC000001 Transistor
Q201 B1BDBC000001 Transistor
Q203 YESAN060 Transistor
CAPACITORs
C101 YESCC203 Chip, 220pF 50WV
C102 YESCC187 Chip, 0.1MFD 25WV
C103 YESCC187 Chip, 0.1MFD 25WV
C104 YESCC206 Chip, 0.047MFD 25WV
C105 F1H1H2220004 Chip, 0.0047MFD 25WV
C106 YESCC207 Chip, 0.001MFD 50WV
C107 YESCC206 Chip, 0.047MFD 25WV
C108 YESCC204 Chip, 330pF 50WV
C109 YESCC187 Chip, 0.1MFD 25WV
C110 YESCC187 Chip, 0.1MFD 25WV
C111 YESCC186 Chip, 0.022MFD 50WV
C112 YESCC183 Chip, 0.0022MFD 50WV
C113 YESCC208 Chip, 0.0015MFD 50WV
C114 YESCC207 Chip, 0.001MFD 50WV
C115 YESCC187 Chip, 0.1MFD 25WV
C116 YESCC187 Chip, 0.1MFD 25WV
C121 YESCC187 Chip, 0.1MFD 25WV
C122 YESCC207 Chip, 0.001MFD 50WV
C123 YESCC186 Chip, 0.022MFD 50WV
C124 YESCC187 Chip, 0.1MFD 25WV
C125 YESCC207 Chip, 0.001MFD 50WV
C126 YESCC210 Chip, 1MFD 16WV
C127 YESCC207 Chip, 0.001MFD 50WV
C128 YESCC205 Chip, 0.22MFD 10WV
C129 YESCC187 Chip, 0.1MFD 25WV
C130 YESCC207 Chip, 0.001MFD 50WV
C131 YESCC187 Chip, 0.1MFD 25WV
C132 YESCC187 Chip, 0.1MFD 25WV
C135 YESCC187 Chip, 0.1MFD 25WV
C136 YESCC187 Chip, 0.1MFD 25WV
C137 YESCC210 Chip, 1MFD 16WV
C138 YESCC210 Chip, 1MFD 16WV
Ref.
No.
Part No. Part Name & Description Remarks
C139 YESCC187 Chip, 0.1MFD 25WV
C140 YESCC187 Chip, 0.1MFD 25WV
C141 YESCC187 Chip, 0.1MFD 25WV
C151 YESCC188 Electrolytic, 10MFD 16WV
C152 YESCC213 Electrolytic, 22MFD 6.3WV
C153 YESCC213 Electrolytic, 22MFD 6.3WV
C154 YESCC215 Electrolytic, 220MFD 10WV
C203 YESCC209 Chip, 0.0033MFD 50WV
C204 YESCC209 Chip, 0.0033MFD 50WV
C205 YESCC187 Chip, 0.1MFD 25WV
C207 YESCC187 Chip, 0.1MFD 25WV
C208 YESCC202 Chip, 22pF 50WV
C251 YESCC215 Electrolytic, 220MFD 10WV
C252 YESCC214 Electrolytic, 47MFD 6.3WV
C253 YESCC215 Electrolytic, 220MFD 10WV
C301 YESCC207 Chip, 0.001MFD 50WV
C302 YESCC207 Chip, 0.001MFD 50WV
C311 YESCC207 Chip, 0.001MFD 50WV
C312 YESCC207 Chip, 0.001MFD 50WV
C321 YESCC187 Chip, 0.1MFD 25WV
C356 YESCC213 Electrolytic, 22MFD 6.3WV
C357 YESCC214 Electrolytic, 47MFD 6.3WV
C358 YESCC213 Electrolytic, 22MFD 6.3WV
C359 YESCC216 Electrolytic, 100MFD 16WV
C360 YESCC188 Electrolytic, 10MFD 16WV
C401 YESCC187 Chip, 0.1MFD 25WV
C402 YESCC187 Chip, 0.1MFD 25WV
C403 YESCC187 Chip, 0.1MFD 25WV
C404 YESCC187 Chip, 0.1MFD 25WV
C405 YESCC187 Chip, 0.1MFD 25WV
C406 YESCC188 Chip, 0.1MFD 26WV
C407 YESCC189 Chip, 0.1MFD 27WV
C408 YESCC190 Chip, 0.1MFD 28WV
C409 YESCC187 Chip, 0.1MFD 25WV
C410 YESCC187 Chip, 0.1MFD 25WV
C411 YESCC188 Chip, 0.1MFD 26WV
C412 YESCC189 Chip, 0.1MFD 27WV
C413 YESCC190 Chip, 0.1MFD 28WV
C414 YESCC191 Chip, 0.1MFD 29WV
C418 YESCC187 Chip, 0.1MFD 25WV
C426 YESCC187 Chip, 0.1MFD 25WV
C433 YESCC210 Chip, 1MFD 16WV
C434 YESCC210 Chip, 1MFD 16WV
C435 YESCC187 Chip, 0.1MFD 25WV
C436 YESCC187 Chip, 0.1MFD 25WV
C437 YESCC210 Chip, 1MFD 16WV
C452 YESCC188 Electrolytic, 10MFD 16WV
C463 YESCC214 Electrolytic, 47MFD 6.3WV
C464 YESCC214 Electrolytic, 47MFD 6.3WV
R435 YESCC187 Chip, 0.1MFD 25WV
RESISTORs
JP101 ERJ8GEY0R00V Chip, 0 ohms 1/8W
JP102 ERJ8GEY0R00V Chip, 0 ohms 1/8W
L302 ERJ6GEY0R00 Chip, 0 ohms 1/10W
L303 ERJ6GEY0R00 Chip, 0 ohms 1/10W
L304 ERJ6GEY0R00 Chip, 0 ohms 1/10W
L305 ERJ6GEY0R00 Chip, 0 ohms 1/10W
R101 ERJ3GEYJ4R7V Chip, 4.7 ohms 1/16W
R103 ERJ3GEYJ152V Chip, 1.5k ohms 1/16W
R104 ERJ3GEYJ471V Chip, 470 ohms 1/16W
R105 ERJ3GEYJ272V Chip, 2.7k ohms 1/16W
R106 ERJ3GEYJ103V Chip, 10k ohms 1/16W
R107 ERJ3GEYJ272V Chip, 2.7k ohms 1/16W
R108 ERJ3GEYJ394V Chip, 390k ohms 1/16W
R109 ERJ3GEYJ154V Chip, 150k ohms 1/16W
R110 ERJ3GEYJ103V Chip, 10k ohms 1/16W
R111 ERJ3GEYJ183V Chip, 18k ohms 1/16W
R112 ERJ3GEYJ244V Chip, 240k ohms 1/16W
R113 ERJ3GEYJ124V Chip, 120k ohms 1/16W
15 CD PLAYER PARTS LIST
30
