Unit CS-A9CK CU-A9CK
Power Source Phase, Voltage,
Cycle
(1)
(3)
Single, 220 - 230, 50 Hz
(2) Single, 220 - 240, 50 Hz
Cooling Capacity kW (kcal/h) (1)
(3)
2.65 - 2.70 (2,280 - 2,320)
kW (BTU/h) (2) 2.65 - 2.65 (9,040 - 9,040)
Heating Capacity kW (kcal/h) (1)
(3)
3.00 - 3.05 (2,580 - 2,620)
kW (BTU/h) (2) 3.00 - 3.05 (10,230 - 10,400)
Moisture Removal l/h (Pint/h) 1.6 (3.4)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) Cooling; 6.8 (240) - 6.8 (240)
Heating; 7.0 (250) - 7.0 (250)
—
Indoor Air (Me) m
3
/min (cfm) Cooling; 8.3 (290) - 8.3 (290)
Heating; 8.0 (280) - 8.0 (280)
—
Indoor Air (Hi) m
3
/min (cfm) (1)
(3)
Cooling; 9.9 (350) - 9.9 (350)
Heating; 10.2 (360) - 10.2 (360)
Cooling; 34.0 (1,200) - 34.5 (1,220)
(2) Cooling; 9.9 (350) - 9.9 (350)
Heating; 10.2 (360) - 10.2 (360)
Cooling; 34.0 (1,200) - 35.0 (1,240)
Indoor Air (SHi) m
3
/min (cfm) Cooling; 10.2 (360) - 10.2 (360)
Heating; 10.2 (360) - 10.2 (360)
—
Noise Level dB (A) Cooling; High 36-36, Low 26-26
Heating; High 38-38, Low 28-28
Cooling; High 48 - 49
Heating; High 48 - 49
Power level (dB) Cooling; High 49 - 49
Heating; High 49 - 49
Cooling; High 62 - 63
Heating; High 64 - 65
Electrical Data Input Power W (1)
(3)
Cooling; 800 - 830
Heating; 700 - 740
(2) Cooling; 830 - 870, Heating; 730 - 780
Running Current A (1)
(3)
Cooling; 3.8 - 3.7
Heating; 3.3 - 3.3
(2) Cooling; 3.8 - 3.7, Heating; 3.4 - 3.3
EER W/W (kcal/hW) (1)
(3)
Cooling; 3.31 - 3.25 (2.85 - 2.80)
W/W (BTU/hW) (2) Cooling; 3.19 - 3.05 (10.9 - 10.4)
COP W/W (kcal/hW) (1)
(3)
Heating; 4.29 - 4.12 (3.69 - 3.54)
W/W (BTU/hW) (2) Heating; 4.11 - 3.91 (14.0 - 13.3)
Starting Current A 17.3
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.0 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 73 (33.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 720
8
CS-A7CKP CU-A7CKP5 / CS-A9CKP CU-A9CKP5 / CS-A12CKP CU-A12CKP5
