Panasonic CS-A12CKP Service Manual

18 Replacement Parts List
<Model: CU-A7CK / CU-A9CK / CU-A12CK>
REF. NO. PART NAME & DESCRIPTION QTY. CU-A7CK CU-A9CK CU-A12CK REMARKS
1 CHASSY ASS’Y 1 CWD50K2073
←
CWD50K2074
2 SOUND PROOF MATERIAL 1 CWG302110
← ←
3 FAN MOTOR BRACKET 1 CWD541030
← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH55413
← ←
5 FAN MOTOR 1 CWA951119
←
CWA951121 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406
← ←
7 PROPELLER FAN ASS’Y 1 CWH03K1006
← ←
8 NUT - PROPELLER FAN 1 CWH56053
← ←
9 COMPRESSOR 1 2RS122D5BC02 QK156PAB QJ208PAA 0
10 ANTI - VIBRATION BUSHING 3 CWH50077 CWH501024
←
11 NUT - COMPRESSOR MOUNT 3 CWH56000
←
CWH4582065
12 CONDENSER 1 CWB32C1258
←
CWB32C1266
13 4-WAY VALVE 1 CWB001012
←
CWB00003 0
14 STRAINER 1 CWB11025
← ←
15 HOLDER COUPLING ASS’Y 1 CWH351023
← ←
16 2-WAY VALVE (LIQUID) 1 CWB021055
← ←
0
17 3-WAY VALVE (GAS) 1 CWB011061
←
CWB011060 0
18 OVERLOAD PROTECTOR 1 CWA121050 CWA121112 CWA121060 0
19 HOLDER - O.L.P. 1 CWH7041200 - -
20 TERMINAL COVER 1 CWH171011 CWH171021
←
21 NUT - TERMINAL COVER 1 CWH7080300 CWH561020
←
22 SOUND PROOF BOARD 1 CWH151022
←
CWH151023
23 CONTROL BOARD 1 CWH102102
← ←
24 TERMINAL BOARD ASS’Y 1 (1)
(2)
(3)
CWA28K1034
CWA28K1034
CWA28C2169
CWA28C2169
CWA28C2169
CWA28C2169
CWA28K1034
CWA28K1034
CWA28K1034
25 CAPACITOR - COMPRESSOR 1 DS371206CPNA
(20µF, 370VAC)
CWA312076
(30µF, 400VAC)
DS371306CPNA
(30µF, 370VAC)
0
26 HOLDER CAPACITOR 1 CWH30057
← ←
27 CAPACITOR - FAN MOTOR 1 CWA31618
(2.0µF, 450VAC)
← ←
0
28 CABINET SIDE PLATE (L) 1 CWE041031A
← ←
29 CABINET SIDE PLATE (R) 1 CWE041032A
←
CWE041033A
30 CABINET FRONT PLATE 1 CWE06K1034
← ←
31 WIRE NET 1 CWD041021A
←
CWD041023A
32 CABINET TOP PLATE 1 CWE031014A
← ←
33 PLATE - C. B. COVER 1 CWH131088
← ←
34 CONTROL BOARD COVER 1 CWH131092
← ←
35 HANDLE 1 CWE161010
← ←
36 OPERATION INSTRUCTIONS 1 (1)
(2)
(3)
CWF563838
CWF563840
CWF563843
←
←
←
←
←
←
37 INSTALLATION INSTRUCTIONS (ENGLISH,
FRANCAIS, ESPANOL & DEUTSCH)
1 CWF612304
← ←
38 INSTALLATION INSTRUCTIONS (ITALIANO,
NEDERLANDS, PORTUGUES & GREEK)
1 (1)
(2)
(3)
CWF612305
-
-
←
-
-
←
-
-
39 INSTALLATION INSTRUCTIONS (RUSSIA) 1 (1)
(2)
(3)
CWF612306
-
-
←
-
-
←
-
-
40 L-TUBE 1 CWH5850080
← ←
41 TUBE ASS’Y (CHECK VALVE/CAPILLARY) 1 CWT01C2639 CWT01C2670 CWT01C2640
42 ELECTRO MAGNETIC SWITCH 1 CWA00059
← ←
0
43 ELECTROLYTIC CAPACITOR 1 CWA32C067
← ←
0
44 ELECTRO MAGNETIC SWITCH 1 K6C2C7A00001
← ←
0
45 TEMPERATURE RELAY 1 CWA14C1009
← ←
0
46 V-COIL COMPLETE 1 CWA43C2069
←
CWA43C2054 0
(Note)
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
•
(1) — CU-A7CKP5, CU-A9CKP5, CU-A12CKP5 (Europe & CIS).
•
(2) — CU-A7CKP5-2, CU-A9CKP5-2, CU-A12CKP5-2 (Oceania).
•
(3) — CU-A7CKP5-6, CU-A9CKP5-6, CU-A12CKP5-6 (Turkey & Tunisia).
82
CS-A7CKP CU-A7CKP5 / CS-A9CKP CU-A9CKP5 / CS-A12CKP CU-A12CKP5
