Panasonic CS-A12PKD

97
WARNING
17. Disassembly and Assembly Instructions
High Voltage is generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with
repair work. Failure to heed this caution may result in electric shocks.
17.1 CS-A9PKD CS-A12PKD
17.1.1 Indoor Electronic Controllers, Cross Flow Fan and Indoor Fan Motor Removal
Procedures
17.1.1.1 To remove front grille
Figure 1
17.1.1.2 To remove electronic controller
Figure 2
