3. SPECIFICATION (HEAT PUMP TYPE)
3.1 CS-A24BD3P / CU-A24BBP5
ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A24BD3P CU-A24BBP5
Cooling Capacity kW 6.50
(BTU/h) (22,200)
Heating Capacity kW 7.10
(BTU/h) (24,200)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 20 Hi 43
cfm Hi 706 1518
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1000 + 100) x 650 900 x 900 x
Net Weight kg (lbs) 40 (88) 80 (176)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
