ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A34BD3P CU-A34BBP5
Cooling Capacity kW 10.45
(BTU/h) (35,600)
Heating Capacity kW 11.20
(BTU/h) (38,200)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 35 Hi 70
cfm Hi 1236 2471
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1500 + 100) x 650 1220 x 900 x
Net Weight kg (lbs) 54 (119) 97 (214)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Starting Method - Direct on-line
Motor Type - 2-pole single
induction
Input kW - Cool/Heat 3.23/
Rated
Output
kW - 2.92
Fan Type, Number of Set Sirocco fan-3 Prop. fan-2
Air Volume Control Three-Step and Auto mode
-
(Remote Control)
Motor Type 4-pole single phase induction
motor
6-pole single
induction
Input kW 0.22 0.24
Rated
Output
kW 0.25 0.05 x 2
Air-heat Exchanger Louvre-fin type Louvre-fin
Refrigerant Control Capillary tube Capillary tube
Refrigerant Oil (Charged) L - SONTEX 200LT (
Refrigerant (Charged) kg (oz) - R-22 4.2 (148)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
F.M, Crankcase heater, High pressure switch,
Transformer
Noise Level (Sound Pressure) dB (A) Hi 43 Lo 40 Cooling 55,
1. Cooling capacities are based on indoor temp. 27°C D.B (80.6°F
