D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air temp. 35°C D.B.
(95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temp. 20° CD.B (68.0°
FD.B.) and outdoor air temp. 7°C D.B. (44.6°F D.B.), 6°C W.B.
(42.8°F D.B.)
ELECTRICAL DATA (50Hz)
MODEL / ITEM
CS-A34BD3P/CU-A34BBP5
Condition by JIS B 8616
Volts V 220 230 240
Phase Single Single Single
Input Power kW Cool 3.95 3.95 3.95
Heat 3.55 3.55 3.55
Running Current A Cool 19.0 19.1 19.2
Heat 17.9 18.0 18.1
Starting Current A 94 99 103
Power Factor % Cool 94 90 86
Heat 90 86 82
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 1~220V, 230V, 240V 50Hz
3.5 CS-A34BD3P / CU-A34BBP8
ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A34BD3P CU-A34BBP8
Cooling Capacity kW 10.45
(BTU/h) (35,600)
Heating Capacity kW 11.20
(BTU/h) (38,200)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 35 Hi 70
cfm Hi 1236 2471
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1500 + 100) x 650 1220 x 900 x
Net Weight kg (lbs) 54 (119) 97 (214)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
