ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A50BD3P CU-A50BBP8
Cooling Capacity kW 14.50
(BTU/h) (49,400)
Heating Capacity kW 15.70
(BTU/h) (53,500)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 45 Hi 86
cfm Hi 1589 3036
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1500 + 100) x 650 1220 x 1100 x
Net Weight kg (lbs) 56 (123) 116 (256)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Starting Method - Direct on-line
Motor Type - 2-pole 3-phase
motor
Input kW - Cool/Heat 4.56/
Rated
Output
kW - 4.1
Fan Type, Number of Set Sirocco fan-4 Prop. fan-2
Air Volume Control Three-Step and Auto mode
-
(Remote Control)
Motor Type 4-pole single phase induction
motor
6-pole single
induction
Input kW 0.30 0.25
Rated
Output
kW 0.20 0.055X2
Air-heat Exchanger Louvre-fin type Louvre-fin
Refrigerant Control Capillary tube Capillary tube
Refrigerant Oil (Charged) L - SONTEX 200LT (
Refrigerant (Charged) kg (oz) - R-22 5.0 (176)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
F.M, Crankcase heater, High pressure switch,
Transformer
Noise Level (Sound Pressure) dB (A) Hi 45 Lo 42 Cooling 56,
