(95°F D.B.), 24°C W.B. (75.2°F W.B.) / / / / / /
ELECTRICAL DATA (50Hz)
MODEL / ITEM
CS-A24BD3P/CU-C24BBP5
Condition by JIS B 8616
Volts V 220 230 240
Phase Single Single Single
Input Power kW Cool 2.59 2.59 2.59
Running Current A Cool 12.1 11.9 11.6
Starting Current A 49 51 52
Power Factor % Cool 97 95 93
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 1~220V, 230V, 240V 50Hz
4.2 CS-A28BD3P / CU-C28BBP5
ITEM / MODEL
Indoor Unit Outdoor
Main Body CS-A28BD3P CU-
Cooling Capacity kW 7.30
(BTU/h) (24,900)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 25 Hi 43
Medium and Low Speed cfm Hi 883 1518
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1000 + 100) x 650 900 x 900 x
Net Weight kg (lbs) 40 (88) 82 (181)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Starting
Method
- Direct on-line
Motor Type - 2-pole single
induction
Input kW - Cool/2.49
Rated
Output
kW - 2.0
