ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A24BD3P CU-C24BBP5
Cooling Capacity kW 6.50
(BTU/h) (22,200)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 18 Hi 43
Medium and Low Speed cfm Hi 636 1518
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 270 x (1000 + 100) x 650 900 x 900 x 320
Net Weight kg (lbs) 40 (88) 80 (176)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Starting
Method
- Direct on-line
Motor Type - 2-pole single
induction motor
Input kW - Cool/2.31
Rated
Output
kW - 1.9
Fan Type, Number of Set Sirocco fan-2 Prop. fan-1
Air Volume Control Three-Step and Auto mode -
(Remote Control)
Motor Type 4-pole single phase
induction motor
6-pole single
induction motor
Input kW 0.15 0.11
Rated
Output
kW 0.15 0.05
Air-heat exchanger Louvre-fin type Louvre-fin type
Refrigerant Control Capillary tube Capillary tube
Refrigerant oil (Charged) L - MS32 (1.3)
Refrigerant (Charged) kg (oz) - R-22 2.5 (88)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
for F.M, Crankcase heater, High pressure
Current Transformer
Noise Level (Sound Pressure) dB (A) Hi 40 Lo 35 Hi 50
1. Cooling capacities are based on indoor temp. 27°C D.B. (80.6°F
D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air temp. 35°C D.B.
