ITEM / MODEL
Indoor Unit Outdoor
Main Body CS-A34BD3P CU-
Cooling Capacity kW 10.45
(BTU/h) (35,600)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 35 Hi 70
Medium and Low Speed cfm Hi 1236 2471
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1500 + 100) x 650 1220 x 900 x
Net Weight kg (lbs) 54 (119) 97 (214)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Starting
Method
- Direct on-line
Motor Type - 2-pole single
induction
Input kW - Cool/2.93
Rated
Output
kW - 2.8
Fan Type, Number of Set Sirocco fan-3 Prop. fan-2
Air Volume Control Three-Step and Auto mode -
(Remote Control)
Motor Type 4-pole single phase
induction motor
6-pole single
induction
Input kW 0.22 0.24
Rated
Output
kW 0.25 0.05 x 2
Air-heat exchanger Louvre-fin type Louvre-fin
Refrigerant Control Capillary tube Capillary
Refrigerant oil (Charged) L - SONTEX 200LT
Refrigerant (Charged) kg (oz) - R-22 4.2 (
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
for F.M, Crankcase heater, High pressure
Current Transformer
Noise Level (Sound Pressure) dB (A) Hi 43 Lo 40 Hi 55
1. Cooling capacities are based on indoor temp. 27°C D.B. (80.6°F
D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air temp. 35°C D.B.
