(95°F D.B.), 24°C W.B. (75.2°F W.B.) / / / / / /
ELECTRICAL DATA (50Hz)
MODEL / ITEM
CS-A34BD3P/CU-C34BBP8
Condition by JIS B 8616
Volts V 380 400 415
Phase 3N 3N 3N
Input Power kW Cool 3.95 3.95 3.95
Running Current A Cool 6.3 6.3 6.3
Starting Current A 39 41 42
Power Factor % Cool 95 91 87
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 3N~380V, 400V, 415V 50Hz
4.6 CS-A43BD3P / CU-C43BBP8
ITEM / MODEL
Indoor Unit Outdoor
Main Body CS-A43BD3P CU-
Cooling Capacity kW 13.00
(BTU/h) (44,300)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 40 Hi 82
Medium and Low Speed cfm Hi 1413 2895
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1500 + 100) x 650 1220 x 1100 x
Net Weight kg (lbs) 55 (121) 114 (251)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Starting
Method
- Direct on-line
Motor Type - 2-pole 3-phase
motor
Input kW - Cool/3.85
Rated
Output
kW - 3.54
