HEATING POWER CONSUMPTION CURVE
RATED HEATING CAPACITY, RATED HEATING POWER CONSUMPTION
MODEL NAME RATED HEATING STANDARD
CAPACITY (kW) POWER CONSUMPTION
(kW)
CS-A24BD3P/CU-A24BBP5 7.10 2.50
CS-A28BD3P/CU-A28BBP5 7.75 2.61
CS-A28BD3P/CU-A28BBP8 7.75 2.40
CS-A34BD3P/CU-A34BBP5 11.20 3.55
CS-A34BD3P/CU-A34BBP8 11.20 3.40
CS-A43BD3P/CU-A43BBP8 14.20 3.90
CS-A50BD3P/CU-A50BBP8 15.70 5.09
