Panasonic CS-A28BB4P Service Manual

NO. PART DESCRIPTION
QTY.
CU-A24BBP5 CU-A28BBP5 CU-A28BBP8
1 BASE PAN ASS’Y 1 CWD52K1038A
2 COMPRESSOR 1 NH41VNDT NH44VNDT NH44YDET
3 ANTI-VIBRATION BUSHING 4 CWH501018
4 NUT FOR COMP. MOUNT. 3 XNG8
4a WASHER for COMPRESSOR 3 XWA8
4b SP WASHER 3 CWH571018
5 CRANKCASE HEATER 1 CWA341005
6 CONDENSER COMPLETE 1 CWB32C1088 CWB32C1089
7 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1045 CWT07K1046
8 PIPE HOLDER RUBBER 1 CWG251016
9 CONDENSER SIDE PLATE 1 CWD911122
11 TUBE ASS’Y(PRESSURE SWITCH) 1 CWT022355
12 HIGH PRESSURE SWITCH 1 CWA101002
13 ACCUMULATOR 1 CWB131007A CWB131008A
13a 4-WAYS VALVE COMPLETE 1 CWB00C1002 CWB00C1003
13b TUBE ASS’Y(PRESS.SW + VALVE) 1 CWT01C2285
13c HEATING PRESSURE SWITCH 1 CWA101001
13d 4-WAYS VALVE 1 CWB00003
15 TUBE ASS’Y(VALVE+STRAINER) 1 CWT01C2282 CWT01C2283
16 3-WAYS VALVE 1 CWB011054 CWB011053
17 STRAINER 1 CWB111006 CWB111005
17a 2-WAYS VALVE 1 CWB02299
18 CAPILLARY TUBE for VALVE 1 CWB15K1038 CWB15K1037
19 PIPE HOLDER RUBBER 1 CWG251014 CWG251015
20 HOLDER-SERVICE VALVE 1 CWD911124
21 SOUND-PROOF BOARD ASS’Y 1 CWH151016
21a SOUND PROOF MATERIAL-COMP 1 CWG302098
22 V-COIL COMPLETE 1 CWA43C2068
189
