Panasonic CS-A28BB4P Service Manual

22a V-COIL COMPLETE (4 WAY VALVE) 1 CWA43C2060
23 PIPING SENSOR (DISCHARGE) 1 CWA501042
24 PIPING SENSOR (COIL) 1 CWA501043
25 SPRING FOR SENSOR 2 CWH711010
26 CABINET REAR PLATE 1 CWE02C1005
27 CONTROL BOARD 1 CWH141004
28 COMPRESSOR RELAY 1 CWA001005 CWA001007
29 TERMINAL BOARD ASS’Y 1 CWA28K1027 CWA28K1029
30 CAPACITOR-FAN MOTOR (3 / 460) 1 DS461305QP-A
30a CAPACITOR-COMP (MF/V)
1
DS441456CPNB / (45 /
440)
DS441506CPNB / (50 /
440)
-
31 ELECTRONIC CONTROLLER 1 CWA742583 CWA742584
32 TRANSFORMER 1 CWA401029
33 CURRENT TRANSFORMER BOARD 1 CWA742591 CWA742592
33a OVERLOAD PROTECTOR 1 - - CWA121075
33b TERMINAL COVER 1 CWH171019 CWH171022
34 BRACKET FAN MOTOR 1 CWD541027
35 SCREW-BRACKET FAN MOTOR 4 CWH551040
36 FAN MOTOR 1 CWA951077
38 SCREW-FAN MOTOR 4 CWH55442
39 PROPELLER FAN 1 CWH001007
40 WASHER for P.FAN 1 CWH571013
41 SPRING WASHER for P.FAN 1 XWB10B
42 NUT for PROPELLER FAN 1 CWH56033
43 P.FAN AIR GUIDER PLATE 1 CWE061036A
44 FAN GUARD 1 CWD041014A
45 CONDENSER GUARD 1 CWD041015A
46 CABINET TOP PLATE COMPLETE 1 CWE03C1004
47 FLARE NUT (1/4”) / (3/8”) 1 6002140 (1/4”) CWT25005 (3/8”)
48 FLARE NUT (5/8”) 1 CWT25004
190
