Panasonic CS-A28BB4P Service Manual

49 PIPE COVER (FRONT) 1 CWD601017A
50 PIPE COVER (BACK) 1 CWD601018A
51 CABINET FRONT PLATE 1 CWE06C1033
52 HANDLE 3 CWE161008
53 HANDLE 1 CWE161009
54 LEADWIRE-COMPRESSOR 1 CWA67C3657 CWA67C3665
55 ACCESSORY COMPLETE 1 CWH82C1105
INSTALLATION INSTRUCTION 1 CWF612231
All parts are supplied from MACC, Malaysia (Vendor Code: 086)
NO. PART DESCRIPTION QTY. CU-C24BBP5 CU-C28BBP5 CU-C28BBP6 CU-C28BBP8
1 BASE PAN ASS’Y 1 CWD52K1038A
2 COMPRESSOR 1 NH41VNDT NH44VNDT NH44NADT NH44YDET
3 ANTI-VIBRATION BUSHING 4 CWH501018
4 NUT FOR COMP. MOUNT. 3 XNG8
4a WASHER for COMPRESSOR 3 XWA8
4b SP WASHER 3 CWH571018
5 CRANKCASE HEATER 1 CWA341005
6 CONDENSER COMPLETE 1 CWB32C1091
7 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1024
8 PIPE HOLDER RUBBER 1 CWG251016
9 CONDENSER SIDE PLATE 1 CWD911122
11 TUBE ASS’Y(PRESSURE SWITCH) 1 CWT022364
12 HIGH PRESSURE SWITCH 1 CWA101002
13 ACCUMULATOR 1 CWB131007A CWB131008A
14 TUBE ASS’Y(3 WAYS VALVE) 1 CWT022362 CWT022363
15 TUBE ASS’Y(VALVE+STRAINER) 1 CWT01C2282 CWT01C2283
16 3-WAYS VALVE 1 CWB011054 CWB011053
17 STRAINER 1 CWB111006 CWB111005
191
