Panasonic CS-A28BB4P Service Manual

ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A28BB4P CU-
C28BBP6
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 7.6
BTU/h 25,900
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 20 Me 18 Lo 16 Hi 43
Medium and Low Speed cfm 706 635 565 1518
Outside Dimension (H x W x D) mm 240 x 840 x 840 900 x 900
x
inch 9-7/16 x 33-1/24 x 33-1/24 35-7/16 x 35-7/
16
Net Weight kg 26 81
lbs 57 179
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
x
Compressor
Type, Number of Set - Hermetic-1 (
Rotary),
Starting Method - Direct on-line
starting
Motor Type - 2-pole single
phase
induction
motor
Input kW - Cool
3.00
Rated
Output
kW - 2.0
Fan Type, Number of Set Turbo fan-1 Propeller
fan
Motor Type 6-pole single phase
induction motor
6-pole single
phase
induction
motor
Input kW 0.09 0.11
Rated
Output
kW 0.04 0.05
Air-heat Exchanger Slit-fin type Louvre-fin
type
Refrigerant Control Capillary tube -
Refrigerant Oil (Charged) litre - MS32 (
1.3)
Refrigerant (Charged) kg
-
(3.8)
lbs (11.1)
Running
Adjustment
Control Switch Wireless or Wired Remote
Control
-
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
thermostat
fan motor, Crankcase heater, High pressure
switch,
Current transformer
Noise Level dB Hi 44 Me 42 Lo 40 Hi 53
1. Cooling capacities are based on indoor temperature of 27°C D.B.
(80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.), and outdoor air
26
