Panasonic CS-A28BB4P Service Manual

temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (60Hz)
ITEM / MODEL
CS-A28BB4P, CU-C28BBP6
Condition by JIS B 8615
Volts V 220
Phase Single
Power Consumption kW Cool 3.20
Running Current A Cool 15.3
Starting Current A 70
Power Factor % Cool 95
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 60Hz
4.4. CS-A28BB4P / CU-C28BBP8
ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A28BB4P CU-
C28BBP8
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 7.1
BTU/h 24,200
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 20 Me 18 Lo 16 Hi 43
Medium and Low Speed cfm 706 635 565 1518
Outside Dimension (H x W x D) mm 240 x 840 x 840 900 x 900
x
inch 9-7/16 x 33-1/24 x 33-1/24 35-7/16 x 35-7/
16
Net Weight kg 26 81
lbs 57 179
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
x
Compressor
Type, Number of Set - Hermetic-1 (
Rotary),
Starting Method - Direct on-line
starting
Motor Type - 2-pole 3-phase
induction
motor
Input kW - Cool
2.47
Rated
Output
kW - 2.0
27
