Panasonic CS-A7BKP

16 Replacement Parts List
<Model: CS-A7BK / CS-A9BK / CS-A12BK>
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-A7BK CS-A9BK CS-A12BK REMARKS
1 CHASSY COMPLETE 1 CWD50C1177
← ←
2 FAN MOTOR 1 CWA921060
← ←
0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1012
← ←
4 BEARING ASS’Y 1 CWH64K007
← ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304
← ←
6 EVAPORATOR 1 CWB30C1143
←
CWB30C1124
7 FLARE NUT 1 CWH6002140(1/4”)
← ←
8 FLARE NUT 1 CWT25005 (3/8”)
←
CWT25007 (1/2”)
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
← ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2101
← ←
11 VERTICAL VANE 12 CWE241068
← ←
12 CONNECTING BAR 2 CWE261024
← ←
13 AIR SWING MOTOR 1 CWA98259
← ←
0
14 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977
← ←
15 CAP - DRAIN TRAY 1 CWH52C1001
← ←
16 HORIZONTAL VANE 1 CWE241070
← ←
17 PARTICULAR PIECE 1 CWD932162
← ←
18 CONTROL BOARD 1 (1)
(2)
(3)
(4)
CWH102103
CWH102103A
-
CWH102103
←
←
CWH102103
←
←
←
←
←
19 TERMINAL BOARD COMPLETE 1 CWA28C2074
←
CWA28C2071 0
20 POWER SUPPLY CORD 1 (1)
(2)
(3)
(4)
CWA20C2159
CWA20C2159
-
CWA20C2159
←
←
CWA20C2195
←
←
←
←
←
21 ELECTRONIC CONTROLLER - MAIN 1 CWA742634 CWA742633 CWA742470 0
22 LEAD WIRE - FAN MOTOR 1 CWA67C3729
← ←
23 ELECTRONIC CONTROLLER - RECEIVER 1 CWA73C1124
← ←
0
24 SENSOR COMPLETE 1 CWA50C608
← ←
0
25 CONTROL BOARD FRONT COVER 1 CWH131090
← ←
26 ELECTRONIC CONTROLLER - INDICATOR 1 CWE39C1042
← ←
0
27 LEAD WIRE - INDICATOR 1 CWA67C3637
← ←
28 INDICATOR HOLDER 1 CWD932163
← ←
29 CONTROL BOARD TOP COVER 1 CWH131091
← ←
30 REMOTE CONTROL COMPLETE 1 CWA75C2166
← ←
0
31 FRONT GRILLE COMPLETE 1 CWE11C2329
← ←
32 INTAKE GRILLE 1 CWE221036
← ←
33 CONTROL PANEL 1 CWE312114
← ←
34 DECORATION BASE (R) 1 CWE351067
← ←
35 DECORATION BASE (L) 1 CWE351068
← ←
36 GRILLE DOOR 1 CWE141033
← ←
37 AIR FILTER 2 CWD001047
← ←
38 SCREW - FRONT GRILLE 2 XTN4+16C
← ←
39 CAP - FRONT GRILLE 2 CWH521062
← ←
40 DRAIN HOSE 1 CWH85287
← ←
41 INSTALLATION PLATE 1 CWH36K1006
← ←
42 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
← ←
43 AIR PURIFYING FILTER 1 CWMD00C0001
← ←
0
44 SOLAR DEODORIZING FILTER 1 CWMD00C0002
← ←
0
(Note)
• All parts are supplied from MACC, Malaysia (Vendor Code: 086).
• “O” marked parts are recommended to be kept in stock.
• (1) — CS-A7BKP, CS-A9BKP, CS-A12BKP (Europe).
• (2) — CS-A7BKP-2, CS-A9BKP-2, CS-A12BKP-2 (Oceania).
• (3) — CS-A9BKP-3, CS-A12BKP-3 (Argentina).
• (4) — CS-A7BKP-6, CS-A9BKP-6, CS-A12BKP-6 (Turkey).
75
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6
