Panasonic CS-A7BKP Service Manual

Note:
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire (1)
(2)
(4)
3 (1.0 mm
2
) —
(3) 3 (1.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 73 (33.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 750
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 44.8 - 53.5 57.0 - 62.0
Rate Output W 15 29
Fan Speed Low rpm (1)
(2)
(4)
Cooling; 780 - 780
Heating; 840 - 840
—
(3) Cooling; 780, Heating; 840 —
Medium rpm (1)
(2)
(4)
Cooling; 960 - 960
Heating; 960 - 960
—
(3) Cooling; 960, Heating; 960 —
High rpm (1)
(2)
(4)
Cooling; 1,140 - 1,140
Heating; 1,230 - 1,230
805 - 820
(3) Cooling; 1,140, Heating; 1,230 805
SuperHigh rpm (1)
(2)
(4)
Cooling; 1,230 - 1,230
Heating; 1,230 - 1,230
—
(3) Cooling; 1,230, Heating; 1,230 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 17
Size (W × H × L) mm 610 × 315 × 25.4 841 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — SUNISO 4GDID or ATMOS
M60 (350)
Refrigerant (R-22) g (oz) — 920 (32.5)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 982, Heating; 325
Flow Rate l/min — Cooling; 5.4, Heating; 13.4
Inner Diameter mm — Cooling; 1.2, Heating; 1.4
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
• Specifications are subject to change without notice for further improvement.
• (1) — CS-A9BKP/CU-A9BKP5 (Europe).
• (2) — CS-A9BKP-2/CU-A9BKP5-2 (Oceania).
• (3) — CS-A9BKP-3/CU-A9BKP5-3 (Argentina).
• (4) — CS-A9BKP-6/CU-A9BKP5-6 (Turkey).
9
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6
