Note: Theillustrationsinthismanualareforexplanationpurposesonlyandmaydifferfromthe
actualunit.Itissubjectedtochangewithoutnoticeforfutureimprovement.
PRODUCT OVERVIEW
Indoor Unit
Outdoor Unit
Air inlet (rear)
Air outlet
Troubleshooting
l Operationdelayedforfewminutesafterrestart.
ä Thisisanormalselfprotectioncontrol.
l Soundlikewaterowingduringoperation.
ä Causedbyrefrigerantowinside.
l Mistemergesfromindoorunit.
ä Condensationeffectduetocoolingprocess.
l Noisyduringoperations.
ä Installationworkcouldbeslantedorintakegrilledidn’tcloseproperly.
l Remotecontrol/displaydoesnotwork.
ä Checkwhetherbatteriesarecorrectlyinsertedorneedreplacement.
l Theunitcannotoperate.
ä Checkeithercircuitbreakeristripped,ortimerisusedcorrectly.
l Outdoorunitemitswater/steam.
ä Condensationorevaporationhappensatpipingsurface.
Air inlet (side)
Verticalairflow
vanes
DischargeVent
Discharge air
Horizontalairflow
vanes
ControlandIndicator
Panel(Signalreceiving)
Air intake
Air filter
n About
• Toturnofforturnontheair
conditioner.
• Operationmode,temperature,fan
speedandOFF/ONtimershouldbe
setbyremotecontrol.
OFF/ON operation button
Auto OFF/ON Button
• Tooperatetheunitifthe 
remote control is misplaced or
malfunctioning.
Action Operation mode
Pressonce. AutomaticOperation
Pressuntil
“beep”sound.
CoolingOperation
• ToOFF,pressagaintheAuto
OFF/ONbutton.
• Toswitchtheremotecontrol
signalreceivingsoundofforon.
1.KeeppressingtheAuto
OFF/ONbuttonforabout10
secondsuntil“beep-beep”
soundtoswitchoffthesignal
receivingsounds.
2.Repeattheabovestepifyou
wanttoswitchonthesignal
receivingsounds.
• Airowdirectiononlycanbe
adjusted manually.
• Verticalairowdirectioncontrol.
1.Pullthevanebytheleftandright
portion gently.
2.Don’tusetheuppermostandthe
lowestvanetoadjust.
3.Don’tletthevanesdownward
continuously for a long time,
otherwisecondensationmaybe
caused around the discharge
vent.
• Horizontalairowdirectioncontrol.
Toadjusthorizontalairowvanes
gentlybyholdingthecontrolhandle
on the top left.
AIR SWING
Intakegrille
