Panasonic CS-C45FFH User Manual

8
IndoorUnit
OutdoorUnit
OFF/ON
POWER TIMER
CS-C45FFH
CU-C45FFH
COOLING
3N~(3-Phase)380V-415V,50Hz
Power/Current
[W] 4710-4800
[A] 8.40-8.40
Refrigerant
[kg]
R22
2.40
Cooling Capacity
[kW] 12.0-12.5
Noise Level
JISC9612[<70dB(A)]
[dB(A)]
53
Conditions1mDistanceMax.cooling 57
Air Circulation
[m
3
/min.] 27.0
Product Weight
[kg]
52
88
Dimensions (H × W × D)
[mm]
1880×600×350
1175 ×900×320
Ambient Temperature [°C] 18-43
Testconditions
1. Cooling: Indoor DryBulbTemp.(°C)27 Outdoor DryBulbTemp.(°C)35
  WetBulbTemp.(°C)19  WetBulbTemp.(°C)24
2. Standardpipinglength:7.5m(IncludesIndoorUnitpipinglength).
3. Airlterisattached.
Model
PRODUCT SPECIFICATION
F566276_EN.indd 8 2008-12-16 10:09:18
