– 46 –
MAC9512086C2
CS-C73KE
Replacement Parts List
<Model: CU-C123KE
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
DESCRIPTION & NAME
CHASSY ASS’Y
FAN MOTOR BRACKET
SCREW – FAN MOTOR BRACKET
FAN MOTOR
SCREW – FAN MOTOR MOUNT
COMPRESSOR
ANTI – VIBRATION BUSHING
NUT – COMPRESSOR MOUNT
CONDENSER
TUBE ASS'Y (STRAINER CAPILLARY)
HOLDER COUPLING ASS'Y
2-WAY VALVE
3-WAY VALVE
SOUND PROOF BOARD
SOUND PROOF MATERIAL
WIRE NET
AIR GUIDER PROPELLER FAN
OVERLOAD PROTECTOR
HOLDER – O.L.P.
TERMINAL COVER
NUT – TERMINAL COVER
CONTROL BOARD
TERMINAL BOARD ASS'Y
CAPACITOR – COMPRESSOR
HOLDER CAPACITOR
CAPACITOR – FAN MOTOR
FUSE HOLDER
FUSE
PROPELLER FAN ASS'Y
NUT – PROPELLER FAN
CABINET SIDE PLATE (RIGHT)
CABINET SIDE PLATE (LEFT)
CABINET FRONT PLATE
HANDLE
CONTROL BOARD COVER
PLATE FOR C.B. COVER
CABINET TOP PLATE
Q’TY
1
1
6
1
4
1
3
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
CU-C123KE
CWD50K658A
CWD54254
CWH55413
CWA95378
CWH55252
2KS224D5CA02
CWH50055
CWH4582065
CWB32C334
CWT01C647
CWH35K062
CWB02514
CWB01480
CWH15288
CWG30911
CWD04197A
CWD31138
CWA67C2166
CWH7041200
CWH17006
CWH7080300
CWH10972
CWA28K217
CWA31647
(30 µF, 370 V)
CWH30057
CWA31227
(1.5 µF, 400 V)
XCSCW011
XBA2C31TR0
CWH00K087
CWH56053
CWE04217A
CWE04220A
CWE06K104A
CWE16037C
CWH13461
CWD91258
CWE03111A
REMARKS
t
t
t
t
t
t
t
t
(Note) ● All parts are supplied from MACC, Malaysia (Vendor Code: 086).
● t marked parts are recommended to be kept in stock.
Untitled-8 6/28/00, 5:20 PM46
