PRODUCT OVERVIEW & OPERATIONS
Front panel
Receiver
Auto OFF/ON button
• Used when remote control is misplaced
or malfunction.
Action Mode
Press once. Auto
Press and hold until 1 beep
is heard, then release.
Cooling
Press the button to turn off.
INDICATOR
Maximum distances: 8m
Horizontal airfl ow
direction louver
• Manually
adjustable.
Vertical airfl ow
direction louver
• Do not adjust
by hand.
Remote control
display
TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote control
display to prevent the unit from starting/stopping improperly.
TO SET TEMPERATURE
• For cool and dry modes, the range of temperature for selection is
16°C ~ 30°C.
• Operating the unit within the recommended temperature could
induce energy saving.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
TO SELECT OPERATION MODE
AUTO mode - For your convenience
• Unit selects the operation mode according to the room
temperature.
• Once auto mode is selected, the unit will operate at the standard
setting temperature.
• To change the standard setting temperature, press
for “HI” or
for “LO”.
Room
temperature
Operation
mode
Standard setting
temperature
HI
(+2°C)
LO
(-2°C)
23°C & above Cool 25°C 27°C 23°C
Below 23°C Dry 22°C 24°C 20°C
COOL mode - To enjoy cool air
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling operation.
e-ion AIR PURIFYING SYSTEM
Do not touch during operation
e-ion fi lters
Active e-ion Power
Module
Active e-ion Generator
PRODUCT OVERVIEW & OPERATIONS
(Green) (Orange) (Orange) (Orange) (Blue)
