Panasonic CS-E15LKEW User Manual

ENGLISH
7
NOTES
NOTES
PATR
O
L/
,
Q
UIET
,
P
O
WERFUL
,
ECO
PATROL
• Can be activated in all modes and can be cancelled
by pressing the respective button again.
Q
UIET
,
P
O
WERFUL
,
ECO
PATROL
• Can not be selected at the same time.
• Can not be activated during “MILD DRY COOLING”
operation is activated.
TO SET THE TIMER
TO SET THE TIMER
• 2 sets of ON and OFF timers are available to turn ON
or OFF the unit at different preset time.
• Complete below procedures to set each timer:
ON
OFF
1
Cancel
Cancel
2
S
ET
Select ON or OFF timer
Set the
time
Confi rm
• Example of application at living room:
Morning: ON
at 07:00 (Wake up)
OFF
at 08:00 (Out for work)
Evening: ON
at 17:00 (Back home)
OFF at 22:00 (Sleep)
• To cancel ON or OFF timer, press
O
N
or
OFF
to
select respective or then press
CANCEL
.
• If timer is cancelled manually or due to power failure,
you can restore the timer again by pressing
O
N
or
OFF
to select respective or then press
SET
.
• Upcoming timer will be displayed and will be activated
in sequence.
• When ON Timer is set, the unit may start earlier (up
to 35 minutes) before the actual set time in order to
achieve the desired temperature on time.
• Timer operation is based on the clock set in the
remote control and repeats daily once set. For clock
setting, please refer to Remote Control Preparation at
back cover.
9
TO MONITOR HUMAN PRESENCE
& ACTIVITY FOR ENERGY SAVING
ECO
PATROL
ECO 1 ECO 2 ECO OFF
+3°C
-3°C
Heat Source & Movement
Low
High
+2°C
-2°C
Set Temperature
None
-1°C
Set Fan Speed
COOL/
DRY Mode
HEAT Mode
*≤ Medium
Fan
+1 tap
• — ECO 1 - To optimize comfort and energy saving.
• --- ECO 2 - To maximize energy saving.
*Applicable during COOL/DRY Mode only.
10
TO ENJOY CLEAN & FRESH AIR
PATROL/
PATROL NORMAL
PATROL - To monitor air quality
• Detects air quality; e-ion operation activates when air
quality is at dirty level.
• Can be activated even when the unit is turned off.
• Patrol starts automatically with the unit switched on with
OFF/ON
.
- To freshen and purify the air
• Generates negative ions to produce fresh air effect and
attract dust which will then be captured at the positively
charged e-ion fi lters.
• Can be activated even when the unit is turned off. In this
condition, fan speed and air swing can not be adjusted.
11
TO ACHIEVE TEMPERATURE
QUICKLY
• This operation will stop automatically after 20 minutes
(For Single Split System).
12
Press and hold for 5 seconds to dim or restore the
unit’s indicator brightness.
13
Press and hold for approximately 10 seconds to
show temperature setting in °C or °F.
14
Press to restore the remote control’s default setting.
15
Not used in normal operations.
FAN SPE
ED
ECO
PATROL
PATROL/
MILD DRY
COOLI
NG
MOD
E
QUIET
TEMP
OFF/ON
AIR
SWI
NG
POW
ERFUL
TIM
ER
SET
CAN
CEL
ON
OFF
1
2
3
SET
CHECK
CLOC
K
RESE
AC
RC
