Panasonic CS-E15NKR Service Manual

23
Indoor CS-E24NKR
Model
Outdoor CU-E24NKR
Performance Test Condition AS
Phase, Hz Single, 50
Power Supply
V 230 240
Min. Mid. Max. Min. Mid. Max.
kW 1.70 7.10 8.10 1.70 7.10 8.10
BTU/h 5800 24200 27600 5800 24200 27600
Capacity
kcal/h 1460 6110 6970 1460 6110 6970
Running Current A - 9.7 - - 9.4 -
Input Power W 430 2.11k 2.48k 430 2.11k 2.48k
W/W 3.95 3.36 3.27 3.95 3.36 3.27
BTU/hW 13.49 11.47 11.13 13.49 11.47 11.13
EER
kcal/hW 3.40 2.90 2.81 3.40 2.90 2.81
Power Factor % - 95 - - 94 -
dB-A 47 / 37 / 34 47 / 37 / 34
Indoor Noise (H / L / QLo)
Power Level dB 63 / 53 / 50 63 / 53 / 50
dB-A 53 / - / 48 53 / - / 48
Cooling
Outdoor Noise (H / L / QLo)
Power Level dB 67 / - / 62 67 / - / 62
kW 1.70 8.00 8.56 1.70 8.00 8.56
BTU/h 5800 27300 29200 5800 27300 29200
Capacity
kcal/h 1460 6880 7360 1460 6880 7360
Running Current A - 10.2 - - 9.9 -
Input Power W 380 2.21k 2.37k 380 2.21k 2.37k
W/W 4.47 3.62 3.61 4.47 3.62 3.61
BTU/hW 15.26 12.35 12.32 15.26 12.35 12.32
COP
kcal/hW 3.84 3.11 3.11 3.84 3.11 3.11
Power Factor % - 94 - - 93 -
dB-A 47 / 37 / 34 47 / 37 / 34
Indoor Noise (H / L / QLo)
Power Level dB 63 / 53 / 50 63 / 53 / 50
dB-A 53 / - / 48 53 / - / 48
Heating
Outdoor Noise (H / L / QLo)
Power Level dB 67 / - / 62 67 / - / 62
Capacity kW 6.2
Input Power kW 2.10
H2
COP W/W 2.95
Capacity kW 9.90
Input Power kW 3.00
Powerful Heat
COP W/W 3.30
Max Current (A) / Max Input Power (W) 14.6 / 3.20k
Starting Current (A) 10.2
Type Hermetic Motor (Rotary)
Motor Type Brushless (4 poles)
Compressor
Output Power W 1.70k

Panasonic CS-E15NKR Specifications

General

Brand	Panasonic
Model	CS-E15NKR
Category	Air Conditioner
Language	English
