Panasonic CS-E15NKR Service Manual

24
Type Cross-Flow Fan
Material ASG30K1
Motor Type Transistor (8-poles)
Input Power W 94.8 - 94.8
Output Power W 40
Cool rpm 890
QLo
Heat rpm 960
Cool rpm 990
Lo
Heat rpm 1060
Cool rpm 1230
Me
Heat rpm 1250
Cool rpm 1470
Hi
Heat rpm 1440
Cool rpm 1530
Indoor Fan
Speed
SHi
Heat rpm 1540
Type Propeller Fan
Material PP
Motor Type DC Motor (8-poles)
Input Power W -
Output Power W 60
Cool rpm 700
Outdoor Fan
Speed Hi
Heat rpm 700
Moisture Removal L/h (Pt/h) 4.1 (8.7)
Cool m
3
/min (ft
3
/min) 11.07 (391)
QLo
Heat m
3
/min (ft
3
/min) 12.42 (439)
Cool m
3
/min (ft
3
/min) 12.54 (443)
Lo
Heat m
3
/min (ft
3
/min) 13.98 (494)
Cool m
3
/min (ft
3
/min) 16.07 (567)
Me
Heat m
3
/min (ft
3
/min) 16.94 (598)
Cool m
3
/min (ft
3
/min) 19.6 (690)
Hi
Heat m
3
/min (ft
3
/min) 20.3 (715)
Cool m
3
/min (ft
3
/min) 20.40 (720)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 20.82 (735)
Cool m
3
/min (ft
3
/min) 56.5 (1995)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 56.5 (1995)
Control Device Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (800)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.70k (60.0)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 795 (31-5/16)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 240 (9-15/32) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 60 (132)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 15.88 (5/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height different m (ft) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Piping
Length for Additional Gas m (ft) 10 (32.8)

Panasonic CS-E15NKR Specifications
