14.2.2. Replacement Parts List (Indoor Unit)
Models:
CS-ME10DD3EG / CS-E15DD3EW / CS-E18DD3EW
REF NO. PART NAME & DESCRIPTION QTY. CS-ME10DD3EG CS-E15DD3EW CS-E18DD3EW REMARKS
1 FLOAT SWITCH 1 CWA12161 ← ←
2 THERMAL FUSE 1 CWA16C1038 ← ←
3 TERMINAL BOARD COMPLETE 1 CWA28K1045J ← ←
6 SENSOR COMPLETE 1 CWA50C2270 ← ←
9 REMOTE CONTROL (RECEIVER) 1 CWA75C2773 ← ←
10 REMOTE CONTROL 1 CWA75C2610X ← ←
11 FAN MOTOR 1 ARW41G8P30AC ← ←
12 EVAPORATOR 1 CWB302123XA CWB302123XB CWB302356X
13 DRAIN PUMP COMPLETE 1 CWB53C1010 ← ←
14 PARTICULAR PLATE-1 1 CWD11024XA ← CWD11026XA
15 AIR GUIDER-1 2 CWD32091 ← ←
16 AIR GUIDER-2 2 CWD32092 ← ←
17 BOTTOM PLATE 1 CWD52259X ← ←
18 BULKHEAD 1 CWD531019 ← ←
19 BRACKET FAN MOTOR 1 CWD541036 ← ←
20 PARTICULER PLATE-2 1 CWD74100 ← ←
22 HOLDER LEAD WIRE-1 1 CWH31103 ← ←
23 PARTICULER PLATE-3 1 CWD90K080 ← CWD90K086
24 PARTICULER PLATE-4 1 CWD90616 ← CWD90635
25 PARTICULER PLATE-5 1 CWD90618 ← ←
26 PARTICULER PLATE-6 1 CWD90766 ← ←
27 CABINET BACK PLATE 1 CWE02079 ← ←
28 CABINET TOP PLATE-1 1 CWE03034 ← ←
29 CABINET TOP PLATE-2 2 CWE03035X ← ←
30 CABINET SIDE PLATE-1 1 CWE04071 ← CWE04079
31 CABINET SIDE PLATE-2 1 CWE04072X ← CWE04080X
42 INSULATION SHEET-1 1 CWG07165 ← CWG07174
43 INSULATION SHEET-2 1 CWG07166 ← CWG07175
44 INSULATION SHEET-3 1 CWG07167 ← CWG07176
45 CROSS-FLOW FAN COMPLETE 1 CWH01C005 ← ←
47 CONTROL BOARD BOX 1 CWH10527 ← ←
48 CONTROL COVER 1 CWH131144X ← ←
49 HOLDER LEAD WIRE-2 1 CWH31044 ← ←
50 HOLDER LEAD WIRE-3 1 CWH31030 ← ←
51 HOLDER LEAD WIRE-4 1 CWD77013 ← ←
53 DRAIN TRAY 1 CWH40C061 ← ←
54 BELT 1 CWH4605008 ← ←
55 BUSHING-1 2 CWH4610440 ← ←
56 CAP-1 (1/4" LIQUID SIDE) 1 CWH52061 ← ←
59 BUSHING-2 1 CWH50147 ← ←
60 BUSHING-3 1 CWH50146 ← ←
61 BUSHING-4 1 CWH51134 ← ←
62 CAP-2 (GAS SIDE) 1 CWH52062 (3/8") CWH52063 (1/2") ←
64 FULCRUM 1 CWH64C015 ← ←
65 GUIDER-1 1 CWH691004 ← ←
66 GUIDER-2 1 CWH69025 ← ←
67 FLARE NUT (1/4") 1 CWT25086 ← ←
68 DRAIN HOSE COMPLETE 1 CWH85C008 ← ←
71 FLARE NUT (GAS SIDE) 1 CWT25087 (3/8") CWT25096 (1/2") ←
81 COVER FOR RECEIVER 1 CWD66132B ← ←
82 RECEIVER PIECE-1 1 CWD90650 ← ←
83 PARTICULER PIECE-1 2 CWD93435 ← ←
85 PARTICULER PIECE-2 2 CWD93436 ← ←
86 CABINET BOTTOM PLATE 1 CWE05012X ← ←
87 HOLDER SENSOR-2 1 CWH32137 ← ←
88 PC BOARD (MAIN) 1 CWA73C1840 CWA73C1841 CWA73C1842
89 TRASFORMER (ON-BOARD) 1 CWA40C1027 ← ←
90 FUSE (250V 3.15A) 1 XBA2C31TRO ← ←
91 ZNR 1 ERZVEAV511 ← ←
92 BAG COMPLETE-1 (SCREWS, HOLDER) 1 CWG86C994 ← ←
93 BAG COMPLETE-2 (SCREWS, BELT, ETC.) 1 CWH82C1277 ← ←
(Note)
• All parts are compliant with EU RoHS legislation.
• All parts are supplied from ACD in Japan.
• “
” marked parts are recommended to be kept in stock.
126
